USB
High Performance SMU Case
4 SMU up to 500mA / -1.0V ~ +6.5V output
4 SMU up to 50mA / -2.0V ~ +7.5V output
8 DUT relay driver
16-bit high resolution A/D converter
PXI 3U
16-bit source/16-bit measure resolution
-6V ~ +6V per channel
4 CHs V/I pulsing output
8-CH relay outputs
4-CH 16-bit high resolution A/D converter
High measurement speed (250k s/S)
PXI 3U
16-bit source/16-bit measure resolution
-10V ~ +50V per channel
4 CHs V/I pulsing output
8-CH relay outputs
4-CH 16-bit high resolution A/D converter
High measurement speed (250k s/S)
PXI 3U // USB
High Voltage DPS
16-bit source/16-bit measure resolution
0V ~ +12V per channel
8 SMU/0.5A per channel
8 CHs V/I pulsing output
16-CH relay outputs
8-CH digitizers designed
8-CH 16-bit high resolution A/D converter
High measurement speed (250k s/S)
Software average measurement function for small signal
PXI 3U
16-bit source/16-bit measure resolution
0V ~ +4V per channel
16 DPS/0.3A per channel
16 CHs V/I pulsing output
16-CH digitizers designed
4M Samples data memory per channel
High measurement speed (250k s/S)
External trigger
16-CH 16-bit high resolution A/D converter
Software average measurement function for small signal
PXI 3U
High Voltage PMU/DPS
32 PMU/32mA per board OR 4 DPS/0.5A OR 2 DPS/1A OR 1 DPS/2A
-1V ~ +10V per channel
FV/MI,FI/MV,FV/MV,FI,MI
